Rigid Dump Trucks

HD1500-8

Productivity on demand

Packed with new and improved features, the Komatsu HD1500-8 Rigid Dump Truck combines industry-leading characteristics with genuine Komatsu design and the latest technology to bring unrivalled value to customers.

The full automatic Komatsu Traction Control System (KTCS) feature
Large retarder capacity achieves both high productivity and safety
Smallest turning radius in class
KomVision with camera and radar for industry leading safety
Komatsu Wireless Monitoring System: Komtrax 5.0, Komtrax Plus

Get the brochure

Komatsu Rigid Dump Trucks

Auto Retard Speed Control (ARSC)

Auto Retard Speed Control (ARSC) allows to easily set a constant downhill travel speed and lets the operator concentrate on steering. Speed can be adjusted appropriately to the slope grade at an increment of 1 km/h by clicking the control lever (± 5 km/h max.)

Komatsu Rigid Dump Trucks

Small turning radius

The MacPherson strut type front suspension has a special A-frame between each wheel and the main frame. The wider space created between the front wheels and the main frame increases the turning angle of the wheels. The larger this turning angle, the smaller the turning radius of the truck.

Komatsu Rigid Dump Trucks

Payload meter (PLM)

The Payload meter (PLM) manages the payload of each hauling cycle and analyzes the truck’s production volume and working conditions for a specific period. Loaded weight is displayed in real time, both on the cab’s monitor and by external display lamps.

Komatsu Rigid Dump Trucks

First-class operator comfort

The wide Komatsu SpaceCab™ with user-friendly controls provides a comfortable and safe work environment. A fully adjustable airsuspended seat dampens vibrations and reduces the fatigue of long shifts. Large front and electric side windows give a superior visibility and increased confidence.

Hydro-pneumatic suspension
Low-noise design
Heated & ventilated air-suspended seat

Komatsu Rigid Dump Trucks

Large LCD colour monitor

Large LCD colour monitor: A large user-friendly colour monitor enables safe, accurate and smooth work. Multilingual and with all essential information available at a glance, it features simple and easy-to-operate switches and multifunction keys that provide fingertip access to a wide range of functions and operating information

Komatsu Rigid Dump Trucks

Safety first

Safe cab access thanks to the low angle of the front stairways with handrails, slip-resistant.

Speed limiter: Maximum travel speed is limited independently for both empty and loaded conditions

KomVision is standard: with 6 networked high definition cameras, it creates a real-time bird’s-eye view on the cab monitor, and eliminates the blind spots on the rear and sides of the machine.

Komatsu Rigid Dump Trucks

Easy maintenance

Battery disconnect switch For convenience in maintenance/ service, a battery disconnect switch is located on the left side of the vehicle, and is accessible from the ground level.

Service center A convenient service center is located on the bottom part of the steering/hoist tank. It facilitates engine oil, coolant, transmission oil, steering & hoist oil, and brake cooling oil refilling at the same location.

Centralized arrangement of filters The filters are centralized for easy service.

Auto greasing system This system automatically supplies grease to each greasing point, at preset times. It is no longer necessary to periodically lubricate with a manual pump. Oil reservoir is accessible to refill from the ground level.

Komtrax Plus continuously monitors your machine’s settings, condition, fuel usage and performance along with operating practices. This comprehensive data set is designed to help prolong your quarry and mining machine’s life, improve its efficiency and optimise production levels and costs.

Environmental data

Komatsu has committed to halving CO2 emissions from 2010 levels by 2030 and we will work to achieve net zero CO2 emissions (carbon neutrality) from our production activities by 2050. In addition, we will deploy the relevant technologies at material suppliers and other partners to help them also achieve carbon neutrality in their operations.
